The HDS MAx Series

Techno’s HDS Max Series CNC Machine is made up of all steel construction, providing the rigid foundation required for ultra-smooth routing results. The HDS Series CNC Router includes a 12 HP HSD automatic tool changer spindle with an 8-position tool rack, and comes standard with a pneumatically operated dust collection hood that concentrates air flow at the cutter, providing optimal dust collection performance. The multi-zone vacuum t-slot table is constructed from very hard Phenolic; an extremely stable material that holds tight tolerances for precision cutting. This CNC machine is connected to a 10HP rotary vane vacuum pump (twin pack optional), for quiet operation. For easy sheet alignment, (3) pop-up pins are included on the HDS Series, and are precisely placed to handle and align various size materials. The HDS Series CNC Machine is powered by brushless AC Servo digital motors and drives, and is powered by an easy-to-use and learn Osai PC based industrial controller.



Featured List

All steel construction

12 HP HSD high frequency automatic tool changer spindle

4-Zone vacuum t-slot table

Material pop-up pins for easy sheet alignment

Osai PC based Industrial grade CNC controller

Brushless digital AC servo motors and drives

Features

Steel Base

The HDS Series base frame is fabricated from heavy-duty tubular steel that is welded, precision machined and stress relieved so that the foundation remains true and steady over the operational life of the machine.

Gantry

The gantry is constructed of tubular steel with reinforcing ribs welded throughout the length of the column which results in a steady firm beam assembly. This quality engineering and workmanship result in smooth precision cutting.​

Spindle

The HDS Series machine comes standard with a 12 HP HSD high frequency automatic tool changer spindle. This precision spindle requires no maintenance, uses industry standard ER collets and ISO 30 tool holders, is fully programmable with speeds from 6000 to 24000 RPM, and comes complete with a pneumatically retractable vacuum hood.

Vacuum Table

The vacuum plenum table surface is multi-zoned which allows the operator to easily switch from full sheet processing to smaller part processing (which requires a smaller segmented area). Zones can be turned off easily via control valves on the front of the machine. Gasketing can also be routed to accommodate various material sizes and styles.

Gantry Uprights

The gantry uprights are cast iron with heavy duty gussets formed into the casting. Each support is machined for housing the various drive assemblies including motors, bearings, and wiring harnesses.

Read More

Vacuum Shroud

The HDS includes a pneumatically operated vacuum hood that has concentrated air flow at the spindle thus efficiently cleaning up the dust and debris as it is routed.

Read More

Drive Train Assembly

The Techno HDS Series CNC Router uses precision helical gear racks on the X and Y axes. The mounting of the rack is inverted to help keep dust and debris from building up on the drive system, ensuring smooth motion and long term reliability. The precision gearbox is directly coupled to the servo motor/pinion. This eliminates belt stretch inaccuracies assuring high-speed machining.

LEARN MORE

Tool Holder Clamp

The Techno HDS Series  CNC Machine comes equipped with a tool holder clamp fixture, providing a much easier way of inserting and tightening the CNC router bits into your tool holder. This method is safer and easier.



Electronics

All the electrical components are housed and wired in a doubled-doored Nema 4 electrical enclosure. This allows for easy access and service when needed. All wiring is tagged so that when service is required, the customer can easily navigate the cabinet.

Tooling

The HDS Series machine includes an 8-position tool rack in the rear of the machine. The position of this rack allows for easy loading and unloading of material from either side of the machine.

Drive Motors

The HDS Series CNC Router utilizes AC Servo motors powered by Yaskowa drives. These motors require no regular maintenance — therefore, reducing any maintenance downtime.

Manual Pulse Generator

The MPG allows the operator to move around the machine, making for easy setup



ABOUT THE OSAI CONTROLLER

The Venture Plus model machine is controlled via an Industrial Osai open series PC based CNC controller. OSAI is based on multi-platform software architecture. The real time multi-task operating system offers accurate and safe axis control that can be completed with the system’s own technological algorithms. Additionally, a standard Windows operating system provides a friendly and familiar operator interface. OSAI combines the ease-of-use, flexibility, and connectivity of a fully equipped Windows PC, with the power, durability, reliability, and serviceability of a true CNC machine controller.

Key features:

  • Full automated tool length offset cycle
  • Remote access
  • Intuitive design and operation
  • Skip functionality
  • Backlash compensation
  • Cutter compensation
  • Full 3D capability with helical interpolation
  • Highly Customizable
  • Built-in editor for shop floor modifications
  • Machine feed rate and spindle override control
  • Continuous step jogging, or convenient hand-held pulse
  • Generator can be used to fine tune positional locations
  • CNC NC code previewer
  • I/O machine status display
  • Convenient vacuum pump switches on console interface
  • Convenient pop-up pin switches on console interface
  • Real time file execution
  • Networkable
  • System includes PC, monitor, keyboard, mouse, and work
  • Platform on the control cabinet
